Trek

Trek Dual Sport 3 Gen 5

Trek Dual Sport 3 Gen 5

Regular price $1,049.99 USD
Regular price Sale price $1,049.99 USD
Sale Sold out
Color: Dark Aquatic
Size

Wheel Size: 27.5-inch

  • Due to supply-chain issues, Specs are subject to change without notice.
View full details

Product Details

Dual Sport 3 is a high-performance, go-anywhere hybrid bike that transitions from pavement to rougher terrain with ease. It has a light frame and a simple 1x Shimano CUES drivetrain with a wide range of gears. Its wide Bontrager Kovee wheels and wide gravel tires soak up bumps and rough terrain for a comfortable, confident ride on pavement, rail trails, and light dirt paths.

IT'S RIGHT FOR YOU IF…
You're looking for a light, fast, and capable hybrid bike with quality parts. You plan to use your bike to explore light trails, hit the pavement for fast fitness rides, run errands, and more.

THE TECH YOU GET
A lightweight aluminum frame with sleek internal cable routing, a lightweight carbon fork, tubeless-ready Bontrager Kovee 650b wheels and wide 50c tires for capability and comfort on varied terrain, and a simple, yet durable 1x10 Shimano CUES drivetrain that ditches the front derailleur for easier operation. Don't worry, the wide-range 11-48 cassette still gives you all the gears you need to conquer hills and crush flats. Plus, powerful disc brakes and mounts for a rack and fenders.

THE FINAL WORD
Dual Sport 3 is fast and efficient on pavement and confident and capable on dirt and gravel trails. It has terrain-smoothing wheels and tires and a sturdy and simple 1x Shimano CUES drivetrain.

WHY YOU'LL LOVE IT
- Stiff wheels and wide tires give you the terrain-smoothing comfort and confidence of a suspension fork without the added weight
- The 1x drivetrain gives you all the gears you need and none you don't
- Versatile gravel tires are fast on pavement and grippy on rougher terrain
- The cables are routed internally, which protects them from the elements and adds to the bike's sleek look.

Sizing

Frame SizeRider Height (cm)Rider Height (in)
X-Small147 - 155 4'10" - 5'1"
Small155 - 165 5'1" - 5'5"
Medium165 - 175 5'5" - 5'9"
Large175 - 186 5'9" - 6'1"
X-Large186 - 197 6'1" - 6'6"

Geometry

Frame sizeSmallMediumLargeX-Large
Wheel size27.5" 27.5"27.5"27.5"
Seat tube (cm)37.5 4246.552
Seat tube angle73.8° 73.3°72.8°71.8°
Head tube length (cm)14 16.51921.5
Head angle69.8° 70.3°70.8°71.8°
Effective top tube (cm)54.5 56.558.561.5
Bottom bracket height (cm)28.9 28.928.928.9
Bottom bracket drop (cm)6 666
Chainstay length (cm)44.7 44.744.744.7
Offset (cm)3.9 3.93.93.9
Trail (cm)8.7 8.387.4
Wheelbase (cm)105.2 106.3107.2107.9
Standover (cm)72.3 76.18084.3
Frame reach (cm)37.8 38.539.140.1
Frame stack (cm)57.3 59.862.465.2

Specs

Pedals Wellgo nylon body, alloy cage
Fork Dual Sport carbon, internal brake routing, fender mounts, rack mounts, ThruSkew 5mm QR
Rims Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23mm width, Presta valve
Stem Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Chain Shimano LG500, 9/10/11 speed
Frame Alpha Gold Aluminum, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR
Tires Bontrager GR0 Elite, wire bead, puncture protection, 60 tpi, 650x50mm
Brakes Shimano hydraulic disc, MT201 lever, UR300 caliper // Shimano hydraulic disc, MT201 lever, UR300 caliper
Rotors Shimano RT26, 6-bolt, 160mm
Saddle Bontrager H1
Crankset Prowheel alloy, 40T narrow-wide ring, 175mm length
Seatpost Bontrager alloy, 27.2mm, 12mm offset, 330mm length
Shifters Shimano CUES U6000 w/optical gear display, 10 speed
Handlebars Bontrager Comp Lowriser, alloy, 31.8mm, 15mm rise, 660mm width
Tape/Grips Bontrager XR Endurance Elite
Rear Derailleur Shimano CUES U6000 GS
Cassette/Freewheel Shimano CUES LG300, LINKGLIDE, 11-48, 10 speed
Hubs Front: Formula DC-20, alloy, 6-bolt, 5x100mm QR Rear: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR

* Subject to change without notice.
